Product Specifications：

Body/Housing Material: Cast Iron Body

Worm wheels Materials: Tin Bronze, Aluminum Bronze, Copper-9-4#

Surface Harness: 56-62HRC

Shaft: Chromium Steel-45#

Input Power: 0.06KW to 15KW

Body Sizes: 40, 50, 60, 70, 80, 100, 120, 135, 147, 155, 175, 200, 250

Single Gear Standard Ratios: 1:5, 1:10, 1:15, 1:20, 1:25, 1:30, 1:40, 1:50, 1:60, 1:70, 1:80, 1:100

Double Gear Ratios: 1:200~900

Product Features：

1. Compact size.
2. The output shaft is integrated by hot extrusion processing, which can afford stronger impact resistance and strength than spline connection
3. All motors are powered up to test withstanding voltage, insulation, noise, temperature rising, and appearance.
4. 100% copper wire, continuously running is no problem.
5. Special grease be poured into the gearhead before delivery, free maintenance.

Product Application：

1. Conveyor system
2. Pharmaceutical machine
3. Automatic Control, Textile Equipment, Conveyor System, Packing Machine
4. Motor, Textile, Printing, Food, Metallurgical,
5. Environmental Protection Engineering, Warehouse Logistics Industry.
